2.7 Delivered Parts, Components and Dimensions - D12M-CS
2.7.1 Delivered Parts and Components - D12M-CS
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
48/132
D12 Camera Manual Part 1
Make sure to check the
delivered parts!
Camera housing (item3.1)
Allen wrench 3mm
(item3.11)
Cable cover (item3.7)
Ethernet cable (item3.10)
Custom tool with mag-
net (item3.12)
Outer shell (item3.9)
Enlarged dome (item3.8),
1x transparent, 1x tinted
2 Objektivträger (item3.3)
1 Objektiv (item3.2)
1 Objektivbrücke (item3.13)
2 Konterringe (item3.4)
D12M-CS
Item Count Part Name
3.1
3.2
1
1
Camera housing
Lens
3.3
3.4
3.5
3.6
2
2
Lens mount
Lock ring
2
8
Ribbon cable
Cable clamp
3.7
3.8
3.9
3.10
1
2
Cable cover
Dome; 1x tinted, 1x transparent
1
1
Outer shell
Ethernet cable
3.11
3.12
3.13
1
1
Allen wrench 3 mm
Custom tool with magnet
1 Lens bridge
Mounting Supply
Item
M.1
Count
3
Part Name
Dowels 10 mm
M.2
M.3
3
3
Stainless steel washers Ø 9mm
Stainless steel wood screws with hex head 8x70mm
