2.6 Delivered Parts, Components and Dimensions - D12D-180°
2.6.1 Delivered Parts and Components - D12D-180°
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
44/132
D12 Camera Manual Part 1
Make sure to check the
delivered parts!
Item Count Part Name
2.1
2.2
1
2
Camera housing
Lens
2.3
2.4
2.5
2.6
2
2
Lens mount
Lock ring
2
8
Ribbon cable
Cable clamp
2.7
2.8
2.9
2.10
1
2
Cable cover
Dome; 1x tinted, 1x transparent
1
1
Outer shell
Ethernet cable
2.11
2.12
2.13
1
1
Allen wrench 3 mm
Custom tool with magnet
1 Lens bridge
Camera housing (item2.1)
Allen wrench 3mm
(item2.11)
Enlarged dome (item2.8),
1x transparent, 1x tinted
Cable cover (item2.7)
Ethernet cable (item2.10)
Custom tool with mag-
net (item2.12)
Outer shell (item2.9)
2 lens mounts (item2.3)
2 lenses (item2.2)
1 lens bridge (item2.13)
2 lock rings (item2.4)
D12D-180°
Mounting Supply
Item
M.1
Count
3
Part Name
Dowels 10 mm
M.2
M.3
3
3
Stainless steel washers Ø 9mm
Stainless steel wood screws with hex head 8x70mm
