First Images and the Most Important Settings
Caution
To permanently save the standard image setting dened for the Q26, go to the Store
CompleteConguration option in the Manage Settings Quick Control. The settings
will then remain in eect, even aer rebooting.
Functions Of The Q26 OnScreen Control
To use the OnScreen Control, click on the arrows in the top area for shiing the image
section. In the bottom areas, which are displayed when needed, click to the le and/or
right of the center point.
The same applies for every area: The further away that you click from an area’s center
point, the greater the change triggered. To reset an area, click on its center point again.
During panorama correction, clicking between the two trapezoid symbols straightens the
le or right tilting lines, which are best visible at the edges of the image section.
Image tilt correction
Panorama correction
Zoom
Tilt down
Pan to the right
Tilt up
Default setting
Close
Pan to the le
Depending on the mounting
position (ceiling, wall, oor),
panorama correction and
mounting error correction
may not be available!
Bring columns together at
the
top (necessary to correct
the example on the le)
Bring columns together
at the
bottom
