SERVICE MENU
57
SQ15- CHECK FOR WATER INJECTION PUMP/EV6 ACTIVATION
- open the door
- from the OTHER
COMPONENTS menu:
- activate WP & injection
pump/EV6
- check that water is supplied to
chamber properly
- perform test only if PT2 - steam
generator temperature is lower
than 70°C
- de-activate the components after
completing the test
SQ16 - CHECK FOR TUBE BUNDLE HEATING ELEMENT ACTIVATION
From the OTHER COMPONENTS
menu:
- activate “BH - chamber tube
bundle heating element”
Proper activation is indicated by
parameter PT3 – chamber tube
bundle heating element
temperature increasing.
SQ17 - CHECK FOR GENERATOR HEATING ELEMENT ACTIVATION
From the OTHER COMPONENTS
menu:
- activate “SG - generator heating
element
Proper activation is indicated by
parameter PT2 – steam generator
heating element temperature
increasing.
