molex Brad HarshIO 600 eIP - Page 31

HarshIO 600 eIP
•
31
•
IP67 IO-Link Modules for EtherNet/IP
Blinking
blue
IOLSx =3 & IOLDx=1
IOLSx =0 & IOLDx=1
The BLUE led shows the actual IO-Link state:
Blinking at 1 Hz: searching device, wakeup mode
Blinking at 2 Hz: device found and in state PREOPERATE
Fixed red
CSx=1
SO: energized and shorted to ground
SO: when overload detected (>500mA)
UVUB =1
All PSx=1
IOLSx # 0 (if configured)
Under voltage (UB <19.2V) when SO energized or IO-Link
configured
OVUB =1
All PSx=1
IOLSx # 0 (if configured)
Overvoltage on UB (> 30 V) when SO energized or IO-Link
configured
OLUB =1
All PSx=1
IOLSx # 0 (if configured)
Overcurrent on UB (>~10A) when SO energized or IO-Link
configured
OLUL =1
All PSx=1
IOLSx # 0 (if configured)
Overcurrent on UL (>~10A) when SO energized or IO-Link
configured
Blinking red
PSx=1
Blinking at 1 Hz: SI: L+ is shorted
Blinking at 1 Hz: SI: L+ is overloaded (1.6A)
IOLSx # 0
Blinking at 2 Hz: IO-Link device connected but validation failed
CSx:
UVx:
OVx:
OLx:
PSx:
IOLSx:
IOLDx:
Channel Status (x = Channel number)
Under Voltage (x = UL or UB)
Over Voltage (x = UL or UB)
Over Load (x = UL or UB)
Port Status (x = Channel number) - state of the pin1 (L+)
IO-Link Status
IO-Link Data Valid
