58
Diagnostics
MSD Single-Axis System Operation Manual AC-AC Servo Drive
ID no.: CA65642-001 06/2018
moog
6.2 Status and error indication in MDA5
Click the "Device status" button in the header for the MDA5 to open the "Device status"
window.
Figure 6.1 "Device status" button in the header
Use the "Error history..." button to retrieve information on the last 20 errors that have
occurred.
Figure 6.2 "Device status" window
On the occurrence of an error, a "pop-up" window appears immediately with more
detailed information on the actual error.
Figure 6.3 Error message
