A.2.6 G395-250 to G395-450, liquid cooling
Designation
Technical data
G395-250
G395-325
G395-450
Output, motor side
1)
Voltage
3)
3-phase U
Mains
Rated current, effective (l
N
) 250A 325A 450A
Peak current See A.1.6
Rotating eld frequency 0 ... 400Hz
Switching frequency of the power stage 2, 4kHz (8, 12, 16)
2)
Input, mains side
Mains voltage (3x230V/ 3x400V/ 3x460V/ 3x480V) ±10%
Device connected load (with mains choke)
173kVA 225kVA 310kVA
Current
1)
(with mains choke) 250A 325A 450A
Asymmetry of mains voltage ±3%maximum
Frequency 50/60Hz ±10%
Power dissipation at I
N
1)
3960W 4800W 6750W
DC link
Capacitance 3600µF 5400µF 7200µF
Brake chopper switch-on threshold 820VDC
1) Data referred to mains voltage 3x400V
eff
and switching frequency of the power stage 4kHz
2) When designing the drive, it is to be taken into account that the maximum output voltage reduces as a function of the active power.
3) Connection of an ext. braking resistor to devices with int. braking resistor not permitted (model G395-xxx-xxx-xx2)!
4) Cooling performance adequate also with optional internal braking resistor
Table A.14 Technical data G395-250 to G395-450 liquid cooling
Designation
Technical data
G395-250
G395-325
G395-450
Minimum ohmic resistance of an externally installed
braking resistor
3.2Ω
3)
2.5Ω
3)
1.7Ω
3)
Brake chopper peak power
with external braking resistor
210kW 269kW 395kW
Option: internal braking resistor 3.3Ω 2.4Ω
Brake chopper continuous power
with internal braking resistor
5000W 6800 W
Brake chopper peak power
with internal braking resistor
204kW 280 kW
Chiller data
Coolant pressure
(rated value / maximum value)
1 / 2bar
Coolant ow rate
4)
(rated value / maximum value)
11 / 13l per min
Feed coolant temperature
The coolant temperature can be between +5 °C (+41 °F) and
+40°C (+104 °F). However, the coolant temperature should
not be more than 10°K below the ambient temperature to
prevent condensation on the heat sink.
1) Data referred to mains voltage 3x400V
eff
and switching frequency of the power stage 4kHz
2) When designing the drive, it is to be taken into account that the maximum output voltage reduces as a function of the active power.
3) Connection of an ext. braking resistor to devices with int. braking resistor not permitted (model G395-xxx-xxx-xx2)!
4) Cooling performance adequate also with optional internal braking resistor
Table A.14 Technical data G395-250 to G395-450 liquid cooling
