2. Instrument Connections
CAUTION
Before using the equipment, connect all the instrument main tubes.
The three-way syringes should also be connected.
>>Otherwise, air or water could leak.
All instruments must be in their specified holders ex- cept when in use.
>>Otherwise, an injury or damage could result from using the vacuum syringe or
some other instrument.
Connect the main tubes for the operator’s instruments to their tray and those for the
assistant to the assistant’s tray. Then put all the instruments in their specified holders. Refer
to the instructions below.
>> Main Tube Connections: Attached installation manual.
Three-way Syringe Body and Nozzle Attachment: Section [5] 6. (4) to [5]6. (6)of this
manual
>> Vacuum Syringe and Saliva Ejector: Section [5] 6. (7) and (8) of this manual
>> Various Instruments: Individual operator’s manuals for each instrument
3.Install the Filters
CAUTION
Filters:
All the filters must be installed before using
the equipment.
>>If the filters and their covers are not properly
installed, the
equipment may not perform
satisfactorily or could be damaged. Also
water, air or vacuum lines could become
plu
ed up.
1
2
3
4
5
6
Vacuum Cut Filter
Basin Filter
Drain Trap Filter
Oil Drain Filter
Water Bacteria Cartridge *
Air Bacteria Cartridge *
The chart shows the various filters which are required and
supplied with the equipment.
Refer to Section [6] Maintenance of this manual for
installation instructions.
* ： Option
To Next Page
