[11] Specifications
General Designation
Dental Treatment Unit
Name
SIGNO G10
Model
TU101
Intended purpose
This product, installed in a dental
clinic, locates a patient to a
position for medical examination,
delivers air, water, vacuum, and
electricity to dental equipment
which is intended to be attached
and operates it, and supplies and
drains water for rinsing out
patient’s mouth.
Classification
Regulated Medical Equipment
(Special Maintenance and
Installation)
Rating
220 / 230 / 240V AC
Frequency
50 / 60 Hz
Power Consumption
1.5 kVA
Weight of Main Unit
Approx. 240 Kg
(with over-arm and step)
Maximum loading
mass
150kg
(Seat: 89kg, Backrest: 61kg)
Seat Elevation
Mechanism
Hydraulic Pantograph
Seat Height
750mm (max.)
400mm (min.)
Backrest Angle
Raised : 70 ± 2°
Lowered : 2 ± 2°
Electric shock
protection
Class I (permanent installation)
Type B with applied device
Water Pressure
0.20 to 0.59 MPa
Air Pressure
0.39 to 0.78 MPa
Three-way Syringe
Output
Water and Spray:
30mL / 15sec.,minimum
Vacuum Syringe
Performance
140 L / min. or more
(When EV-12 is connected)
Maximum Electrical
Load
Warmer Tank : 190W
Three-way Syringe Tube:20W
Maximum
Permissible Load
Foot Control Main Pedal:1350N
Liquid Invasion
Foot Control IP X 1
Operation Cycles
Chair: 50sec. ON, 5min. OFF
Penviewer Intra-oral camera:
50sec. ON, 5min. OFF
Other portions:
Continuous Operation
Type B applied parts
Seat, Headrest, Backrest,
Armrest, Instruments
Vacuum Cut Filter
0.4mm x 0.4mm mesh
