General Radio Operation
Physical Features of the XTS 5000 Model II
Radio
Programmable Controls
The following radio controls can be programmed to operate certain
software-activated features.
The features that can be assigned to these controls by a qualified
radio technician, and the pages where these features can be found
are listed in Table 2 on page 5.
Any references in this manual to controls that are
“preprogrammed” mean that a qualified radio technician must
use the radio’s programming software to assign a feature to a
control.
Table 1: Physical Features
No. Feature Page No. Feature Page
1 Antenna 18 8 Home Button 10
2 On/Off/Volume Control
Knob
21 9 Battery 15
3 LED 11 10 App Button 11
4 Microphone – 11 Display 5
5 PTT (Push-to-Talk)
Button
– 12 Speaker –
6 Menu Select Buttons 8 13 Universal Connector 20
7 4-Way Navigation
Button
11 – –
No. Feature No. Feature
14 Side Button 2 18 Top Button
15 Side Button 1 19 2-Position Concentric Switch
16 Top Side (Select) Button 20 16-Position Select Knob
17 3-Position A/B/C Switch –
