ASTRO XTS 5000 Model II 41
Common Radio Features
Lists
You can use lists to store frequently used numbers and associate
them with names. There are four list types:
•Call
Page
Phone
Scan
View a List
Scan List Empty
1 Press u to find VIEW.
2 Press D, E, or F
directly below VIEW.
3 Press v or u to see the
names of available lists.
4 Press D, E, or F
directly below the name of the
list you wish to view. You see
the first list member.
p indicates the view mode.
5 Press v or u to view other
list members.
6 Press h to exit.
If you wish to view a scan list and
the list has no entries, you see
EMPTY LIST.
To end this display, turn scan off
or edit the list.
VIEW
CALL
PAGE PHON
FIRE CHIEF p
701234
EMPTY LIST
94C26_XTS5000Mdl2.book Page 41 Friday, June 25, 2010 5:23 PM
