8
General Radio Operation
Menu Entry (Softkey)
The bottom row of the display contains one to three menu entries
(also known as softkeys). The menu entries allow you to select one of
several menus to access the radio’s features. The menu entries are
accessed through the Menu Select buttons.
Menu Select Buttons
The Menu Select buttons access the menu entries of features that
have been activated by a qualified radio technician. Your radio may
be programmed differently from the following example, but the display
User Login Indicator (IP Packet Data)
• On (Tinted) = User is currently
associated with the radio;
• Off (Not tinted) = User is currently not
associated with the radio;
• Blinking = Device registration or user
registration with the server failed due
to an invalid username or pin.
99
Table 3: Status Symbols (Continued)
Symbol Indication Page No.
94C26_XTS5000Mdl2.book Page 8 Friday, June 25, 2010 5:23 PM
