ASTRO XTS 5000 Model II 7
General Radio Operation
r
Talkaround
• On = you are talking directly to
another radio, not through a repeater,
during conventional operation only
• Off = you are talking through a
repeater
70 – 71
C
Monitor (Carrier Squelch)
The selected channel is being monitored
during conventional operation only.
30, 34,
35
c
c
Secure Operation
• On = secure operation
• Off = clear operation
• Blinking = receiving an encrypted
voice call
73
T
Scan
The radio is scanning a scan list.
42 – 48
S
(Dot
Blinking)
Priority-One Channel Scan
One channel is assigned as the priority
channel during scan operation.
42 – 47
S
(Dot Steady)
Priority-Two Channel Scan
Two channels are assigned as the priority
channels during scan operation.
42 – 47
Location Signal
• Off = Location feature disabled, or
insufficient battery power in location
accessory device;
• Blinking = Location feature enabled,
but no location signal available;
•On = Location feature enabled, and
location signal available
92 – 96
Table 3: Status Symbols (Continued)
Symbol Indication Page No.
