General Radio Operation
Mode Select Button
This feature lets you program the current zone and channel to a
Mode Select button with a long press on the Mode Select button.
After the buttons are programmed, you can return to the pre-
programmed zone and channel with a short press on the
programmed Mode Select button.
The buttons that are assigned for this feature are labeled in the
following picture.
Top Side Button
Side Button 1
Side Button 2
Top Button
94C26_XTS5000Mdl2.book Page 26 Friday, June 25, 2010 5:23 PM

Motorola ASTRO XTS 5000 Specifications

General

Channel Capacity	1000 Channels
Emergency Button	Yes
GPS	Optional
Frequency Range	136-174 MHz, 380-470 MHz, 764-870 MHz
Dimensions	5.5 x 2.5 x 1.5 inches
Water Resistance	IP67
Digital Protocol	APCO P25 Phase 1 and Phase 2
Encryption	AES, DES
Display	LCD with backlight
MIL-STD-810	Meets MIL-STD-810 C/D/E/F/G
Battery Type	Li-Ion
Operating Temperature	-30°C to +60°C
