Motorola ASTRO XTS 5000 User Manual

16
General Radio Operation
Attach the Battery
Remove the Battery
1 With the radio turned off,
insert the top edge of the
battery into the radio’s frame
as shown.
2 Rotate the battery toward the
radio and press down until
the battery clicks into place.
1 With the radio turned off,
press the release button on
the bottom of the battery until
the battery releases from the
radio.
2 Remove the battery from the
radio.
Note: If your radio is programmed with volatile-key retention,
encryption keys will be retained for approximately 30
seconds after battery removal. Consult a qualified radio
technician for details.
94C26_XTS5000Mdl2.book Page 16 Friday, June 25, 2010 5:23 PM

Motorola ASTRO XTS 5000 Specifications

General

Brand	Motorola
Model	ASTRO XTS 5000
Category	Portable Radio
Language	English
