Chapter 3
Charger Overview
Figure 1: Charger Overview
1
15
14 13
18
19
2 3 4 5 6
7 8 9 10 11 12
1
15
14 13
16
17
2 4 5 6
7 8 9 10 11 12
3
Table 5: Charger Overview and Description
Item Description
1–6 Pocket #1 through Pocket #6
7-12 Pocket #7 through Pocket #12
13 Menu Selection Keypad
14 Keypad Display
15 LED Status Indicator (One per pocket)
16 USB port (With Dust Cover)
MN009418A01-AD
Chapter 3: Charger Overview
11
