Chapter 7
Analyzer Mode
When and where to use: The charger keypad is located below the Pocket 1 display.
Procedure:
1. To enter Analyzer Mode, press the OK button from more than 3 seconds.
The display shows Press OK to entr ANALYZER MODE.
Figure 14: Menu Display Button for Entry to Analyzer Mode
Item Descriptions
1 OK Button
2. Press OK to display data available from the battery
.
7.1
Version V1.0 Analyzer Mode
In software version V1.0, Analyzer Mode is limited to Pocket 1. Analyzer information regarding Pocket 1 and
its contents are presented on the Pocket 1 display.
If no keypad button is pressed for 10 minutes, the charger exits Analyzer Mode and returns to normal
message displays.
MN009418A01-AD
Chapter
7: Analyzer Mode
34
