Motorola LI4278 LINEAR IMAGER Product Reference Guide

ADVANCED DATA FORMATTING 12 - 29
Send Pause
Scan the bar code below to insert a pause in the transmission of data. See Pause Duration on page 12-8 to set
the length of this pause.
Move Cursor (continued)
Move Cursor to Last Occurrence of String and Replace All
Skip to End
Send Pause

Motorola LI4278 LINEAR IMAGER Specifications

General

Scan Rate	547 scans per second
Decode Capability	1D barcodes
Scan Pattern	Single line
Light Source	LED
IP Rating	IP42
Scanner Type	Linear Imager
Battery	Rechargeable Li-ion battery
Drop Specification	1.8 m (6 ft) drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Technology	Linear Imager
Radio Range	Up to 100 m (330 ft) in open air
Interface	USB, RS232, Keyboard Wedge
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% (non-condensing)
Weight	7.9 oz./224 g
Dimensions	9.8 cm H x 7 cm W x 18.6 cm L (3.8 in H x 2.7 in W x 7.3 in L)
