4 - 26 LI4278 Product Reference Guide
Page Button
The CR0078-P cradle offers a page button (see CR0078-P Series Cradle on page 1-6). The page button is a
sensor that when touched, causes paired scanners to emit a beeping sequence. The default is Disable Page
Button.
1. Place your finger over the button sensor .
2. Press down for approximately 1 second.
3. The cradle LED will turn blue when the scanner is out of the cradle. The paired scanner will beep five
times. If multiple scanners are paired to the cradle, all the scanners will beep five times.
4. Repeat as necessary.
Scan one of the following bar codes to enable or disable this feature.
NOTE Scanners out of radio range will not beep when paged. Refer to Technical Specifications on page 3-9 for
detailed radio range information.
*Disable Page Button
Enable Page Button

Table of Contents

Other manuals for Motorola LI4278 LINEAR IMAGER

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Motorola LI4278 LINEAR IMAGER and is the answer not in the manual?

Motorola LI4278 LINEAR IMAGER Specifications

General IconGeneral
Scan Rate547 scans per second
Decode Capability1D barcodes
Scan PatternSingle line
Light SourceLED
IP RatingIP42
Scanner TypeLinear Imager
BatteryRechargeable Li-ion battery
Drop Specification1.8 m (6 ft) drops to concrete
Operating Temperature14°F to 122°F (-10°C to 50°C)
TechnologyLinear Imager
Radio RangeUp to 100 m (330 ft) in open air
InterfaceUSB, RS232, Keyboard Wedge
Storage Temperature-40°C to 70°C (-40°F to 158°F)
Humidity5% to 95% (non-condensing)
Weight7.9 oz./224 g
Dimensions9.8 cm H x 7 cm W x 18.6 cm L (3.8 in H x 2.7 in W x 7.3 in L)
