RADIO COMMUNICATIONS 4 - 5
Bluetooth
Technology Profile Support
With Bluetooth Technology Profile Support, the cradle is not required for wireless communication. The linear
imager scanner communicates directly to the host using Bluetooth technology. The linear imager scanner
supports the standard Bluetooth Serial Port Profile (SPP) and HID Profiles which enable the linear imager
scanner to communicate with other Bluetooth devices that support these profiles.
•
SPP - the linear imager scanner connects to the PC/host via Bluetooth and performs like there’s a serial
connection.
•
HID - the linear imager scanner connects to the PC/host via Bluetooth and performs like a keyboard.
Master/Slave Set Up
The linear imager scanner can be set up as a Master or Slave.
When the linear imager scanner is set up as a Slave, it is discoverable and connectable to other devices.
When the linear imager scanner is set up as a Master, the Bluetooth address of the remote device to which a
connection is requested is required. A pairing bar code with the remote device address must be created and
scanned to attempt a connection to the remote device. See the Pairing Bar Code Format on page 4-21 for
information about creating a pairing bar code.
Master
When the linear imager scanner is set up as a Master (SPP), it initiates the radio connection to a slave device.
Initiating the connection is done by scanning a pairing bar code for the remote device (see Pairing Bar Code
Format on page 4-21).
Slave
When the linear imager scanner is set up as a Slave device (SPP), the linear imager scanner accepts an
incoming connection request from a remote device.
NOTE The number of linear imager scanners is dependent on the host’s capability.
