SCANNING 2 - 5
Cradle LED Definitions
IMPORTANT When the scanner is inserted into the CR0078-S (standard) cradle, the scanner's LED is used as the
charging indicator.
When the scanner is inserted into the CR0078-P (presentation) cradle, the cradle's LED is used as
the charging indicator.
NOTE The CR0078-S/CR0008-S cradles’ LED indicate power only.
Table 2-2
CR0078-P Cradle LED Definitions
LED Indication
Green Blinking Cradle is externally powered and connected to a USB host interface which has
suspended the cradle. The cradle is no longer connected to the linear imager
scanner but it will charge the linear imager scanner. Scan the pairing bar code to
pair the scanner and cradle (see
Pairing on page 4-19
).
Red Blinking Transmission error.
Green Cradle is powered.
Red Blinking Transmission error.
Green Slow Blinking Non-critical battery temperature fault.
Green Slow Blinking Charging in cradle with USB (bus powered).
Green Fast Blinking The scanner is charging.
Amber Blinking Critical battery temperature fault.
Green Solid The scanner is fully charged.
Red Solid Battery requires precharge.
Red Slow Blinking Battery is reconditioning.
