Motorola MC55 User Manual

1 - 6 MC55 User Guide
To install the SIM card:
1. Lift rubber access door.
2. Slide the SIM card holder up to unlock.
3. Lift the SIM card holder door.
Figure 1-5 Lifting the SIM Cover
4. Insert the SIM card, as shown in Figure 1-6 ensuring that the card slides into the holding tabs on each side of
the door.
Figure 1-6 Inserting the SIM Card
5. Close SIM card holder door and slide down to lock into place.
6. Close the rubber access door.
7. Install the battery.
NOTE For more information about SIM cards, refer to the service provider's documentation.
NOTE For detailed information about WWAN activation and settings, refer to the MC55 Integrator Guide.

Motorola MC55 Specifications

General

Barcode Scanner	1D laser scanner or 2D imager
Operating System	Windows Mobile 6.1
Display	3.5 in. QVGA color display
Wireless Connectivity	Wi-Fi 802.11 a/b/g, Bluetooth 2.0
GPS	Optional
Expansion Slots	SD slot
Camera	Optional
Keyboard	QWERTY
