Motorola MC55 - Connection Setup; Indicators

Accessories 6 - 5
Connection Setup
Figure 6-3 Connection Setup
Figure 6-4 Connection Switch
Indicators
Figure 6-5 Indicators
• Spare Battery Charging LED - Indicates the charging status of the spare battery.
• Ethernet/Modem LED - Blink whenever Ethernet or modem connectivity is established.
• Speed LED (green)- Indicates that the transfer rate is 100 Mbps. When it is not lit it indicates that the transfer
rate is 10 Mbps.
Power
Supply
Ethernet Port Power Port
AC Line Cord
USB Port Phone Port
Ethernet Hub
Modem USB Ethernet
Ethernet/Modem LEDSpare Battery
Charging
LED
Speed LED Link LED
