Motorola MC55 User Manual

Getting Started 1 - 13
Figure 1-11 Wireless Manager Menu
Handstrap Replacement
Removal
To remove a handstrap from the MC55:
1. Slide the handstrap clip out of the handstrap slot.
Figure 1-12 Handstrap Clip Removal
2. Press the red Power button to suspend the MC55.
On the MC55A0, the PowerKey Action window appears. Tap Safe Battery Swap. The Decode LED lights red
and then turns off.
3. Remove the battery.
4. Using a small flat screwdriver, push the head of the screwdriver between the handstrap pin and the bottom of
the housing as shown below.
CAUTION When removing handstrap pin, be carefully not to damage handstrap mounting area.

Motorola MC55 Specifications

General

Barcode Scanner	1D laser scanner or 2D imager
Operating System	Windows Mobile 6.1
Display	3.5 in. QVGA color display
Wireless Connectivity	Wi-Fi 802.11 a/b/g, Bluetooth 2.0
GPS	Optional
Expansion Slots	SD slot
Camera	Optional
Keyboard	QWERTY
