Using the MC55 2 - 19

Talk/Start Menu Talk (Green Phone): press to display the phone keypad window or to dial a phone number

(from the phone keypad window).

When on a phone call, press to place the call on hold.

Use this key in conjunction with the Blue key to instantly display the Start menu from any

application without tapping the screen. This function is user programmable.

MC5590:

To use a key as an application key (APP key) on the keyboard, create and install a new

keyboard remap table. However, to remap the green phone key as APP keys through the

registry, create an XML provisioning file that includes the following entry:

[where xx is the new APP key code]

Provision the file to the MC55 to send an APP key code, instead of the original key code,

upon pressing the green phone key. Refer to the MC55 Integrator Guide for information on

creating XML provisioning files.

Scan (yellow)

Activates the scanner/imager in a scan enabled application.

End/OK End (Red Phone): press when the phone keypad window displays to stop dialing or end a

call.

Use this key in conjunction with the Blue key as an OK or close button. This function is user

programmable.

To use a key as an application key (APP key) on the keyboard, create and install a new

keyboard remap table. However, to remap the red phone keys as APP keys through the

registry, create an XML provisioning file that includes the following entry:

[where yy is the new APP key code]

Provision the file to the MC55 to send an APP key code, instead of the original key code,

upon pressing the red phone key. Refer to the MC55 Integrator Guide for information on

creating XML provisioning files.

Scroll Up and Left

Moves up one item.

Moves left one item when pressed with the Orange key.

Scroll Down and

Right

Moves down one item.

Moves right one item when pressed with the Orange key.

Table 2-8

MC55 Numeric Keypad Descriptions (Continued)

Key Description
