1 - 10 MC75A Enterprise Digital Assistant User Guide
Figure 1-11 Removing the Battery Cover
7. Lift the top of the battery cover and remove.
8. Press the battery release latch on the bottom of the battery to unlock, and lift the battery out of the well.
9. Insert the replacement battery, top first, into the battery compartment in the back of the MC75A.
10. Press the battery down into the battery compartment until the battery release latch snaps into place.
11. With the battery cover latches open, insert the cover, bottom first, then press down on the top of the cover.
12. Close the battery cover latches on either side of the battery cover.
13. Press the red Power button to power on the MC75A.
Battery Cover Latch
NOTE Position the battery correctly, with the battery charging contacts on top of the charging contacts in the battery
compartment.
