98
Radio Wide SECURE
Options
From the MAIN MENU, press F4, F3, F2 and F6 to access this screen.
This screen can be accessed only when the SECURE Equipped field is set to
Yes on the RADIO WIDE OPTIONS screen (F4/F3/F2). This screen allows
you to set up various SECURE options that affect Radio wide operation.
Press Tab to select the desired field, or press the desired function key
(F1 - F10). If a field is highlighted, press the UP/DOWN arrow keys to
select the desired choice or value.
Field Definitions
XL IC Present Use the UP/DOWN arrow keys to specify whether or not an XL chip is
present. This field should be set to Yes if the radio is equipped with an
XL chip.
The default is No.
Tx Clear Alert Tones Use the UP/DOWN arrow keys to enable/disable Tx Clear Alert Tones
for the radio. When this field is set to Enabled, an alert tone will be
generated every time the user keys up the radio in the Clear mode.
The default is Enabled.
Periodic Keyfail Alert Tone Use the UP/DOWN arrow keys to enable/disable Periodic Keyfail Alert
Tones for the radio. When this field is set to Enabled, a periodic alert
tone will be generated whenever the radio has lost key and one of the
following conditions is met:
❒ SECURE/Clear Strapping is set to SECURE
❒ SECURE/Clear Strapping is set to Select and the user has selected
SECURE position
The default is Enabled.
DCBF
MOTOROLA Radio Service Software Enter or Scroll to Select Value.
MCS Model:
..CONFIG:RADIO OPTIONS:SECURE OPTIONS
RADIO WIDE SECURE OPTIONS
-------------------------
XL IC Present........................Yes
Tx Clear Alert Tones.............Enabled
Periodic Keyfail Alert Tone......Enabled
Non-XL Scan Unsquelch Duration (ms)..275
XL Scan Unsquelch Duration (ms)......875
Secure Punch Thru.............. Disabled
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP EXIT
To Next Page
