Motorola MCS 2000 User Manual

52
Transmit Current
Limit
From the MAIN MENU, press F2 twice and then F9 to access the
TRANSMIT CURRENT LIMIT screen.
800/900 MHz Models Only
UHF/VHF Models Only
Transmit Current Limit should be checked every time the RF Board is
replaced. This alignment procedure limits the transmitter current
drain of the radio.
Refer to your Radio Service Manual for the Transmit Current Limit
Alignment procedure.
BBI
MOTOROLA Radio Service Software Use UP/DOWN Arrows To Adjust Softpot.
MCS Model:
...CURRENT LIMIT
CURRENT LIMIT
-------------
Frequency Current Value New Softpot Value
--------- ------------- -----------------
177.9875 27 27 ( > 14.5V)
0 (11.9-14.5V)
( < 11.9V)
Transmitter..Off
0 63
MIN |----+----+----+----+----X----+----+----+----+----+----+----| MAX
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP TOGGLE PROGRAM EXIT
PTT VALUE
MOTOROLA Radio Service Software Use UP/DOWN Arrows To Adjust Softpot.
MCS Model:
...CURRENT LIMIT
CURRENT LIMIT
-------------
Frequency Current Value New Softpot Value
--------- ------------- -----------------
136.0125 38 38
144.0125 38 38
154.0125 38 38
160.0125 38 38
167.5125 38 38
173.9875 38 38
177.9875 38 38
Transmitter..Off
0 63
MIN |----+----+----+----+----+----+----+X---+----+----+----+----| MAX
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP TOGGLE PROGRAM EXIT
PTT VALUE
!
Caution
This procedure should be attempted only by qualified
service personnel. Failure to perform alignment
procedures properly may result in seriously degraded
radio or system performance.
