215
Conventional
Personality Phone
Options
From the MAIN MENU, press F4, F6, F3 and then F8 to access this
screen.
This screen allows the user to edit the Conventional phone
conļ¬guration for each Conventional personality. Press Tab to select
the desired ļ¬eld, or press the desired function key (F1 - F10). If a ļ¬eld
is highlighted, use the UP/DOWN arrow keys to select the desired
choice or value.
Function Key Descriptions
F3 - PREV PERS Accesses the previous personality.
F4 - NEXT PERS Accesses the next personality.
Field Deļ¬nitions
Personality Use the UP/DOWN arrow keys to select the desired Conventional
Personality. The number may also be entered directly.
Note: Refer to the Motorola Radio Catalog Sheets for the
maximum number of personalities allowed for this model.
Auto Access Code Select Use the UP/DOWN arrow keys to select an Auto Access Code for this
personality. The radio contains a table for DTMF Access and Deaccess
code pairs and the personality points to one of the table entries. The
actual four-digit codes are entered on the RADIO WIDE PHONE
CONFIGURATION screen (F4/F3/F4).
The default is 1.
DFCH
MOTOROLA Radio Service Software Enter or Scroll to Select
MCS Model: Personality.
MAIN:CHANGE/VIEW:CONV:PERS:PHONE
Personality... 1
CONVENTIONAL PERSONALITY PHONE OPTIONS
--------------------------------------
Auto Access Code Select..........1 -*1P#
DTMF Access Timing Table...............1
Initial Delay (ms)................1000
Digit Duration (ms)................125
Integer Delay (ms)..................75
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP PREV NEXT EXIT
PERS PERS
