258
Trunking Print Menu At the MAIN MENU, press F5 and then F4 to bring up the TRUNKING
PRINT MENU.
You must use the GET/SAVE functions to first read or get a codeplug for
printing radio configuration data. The PRINT function is used to produce
permanent records of codeplug configurations. A printer is required
and should be connected to your computer according to the
instructions in the user’s manual that came with your computer.
Graphics capability is NOT required.
Each print-out contains radio model and serial number information,
software version numbers, Radio Service Software version numbers,
and the date and time of the print-out.
Note: When printing, misalignment of page breaks may result if the
printer is not set up properly. For best results, configure the printer
as an IBM ProPrinter or an Epson FX/MX having factory default
settings. The default number of lines per page is 66.
Function Key Descriptions
F2 - TRUNK WIDE OPT Prints information about options which are applicable to all Trunking
operations, regardless of system type.
F3 - TRUNK SYS Prints Trunking system information.
F4 - TRUNKING PERSONALITY Prints the Trunking personality and talkgroups.
F5 - TRUNK ID LIST Prints the screen which documents the Trunking call lists.
F7 - CONTROL CHANNEL Prints the CONTROL CHANNELS screen (VHF/UHF only).
ED
MOTOROLA Radio Service Software Select Function F1 - F10.
MCS Model:
MAIN:PRINT:TRUNKING
TRUNKING MENU
-------------
F1 - HELP
F2 - Trunking Radio Wide Options
F3 - Trunking Systems: System ID, Control Channels, etc.
F4 - Trunking Personality: Talk Groups, Emergency options, etc.
F5 - Trunking Call List Data
F6 -
F7 - Control Channels (UHF and VHF only)
F8 -
F9 -
F10 - EXIT, Return to PRINT MENU
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP TRUNK TRUNK TRUNK TRUNK ID CONTROL EXIT
WIDE OPT SYS PERS LIST CHANNEL
