153
Channel
Assignment Data
(UHF/VHF models
only)
From the MAIN MENU, press F4 twice, F3 and then F6 to access this
screen.
This screen is used to enter the Channel Assignment Data used for
Other Band Trunking or OBT. Three different frequency splits may be
defined for each system. After the receive and transmit ranges are
defined, press F6 to enter Control Channel frequencies.
Note: This information must match the Central Controller exactly or
the system will not work.
Press Tab to select the desired field, or press the desired function key
(F1 - F10). If a field is highlighted, use the UP/DOWN arrow keys to
select the desired choice or value.
Function Key Descriptions
F3 - PREV SYSTEM Accesses the previous system.
F4 - NEXT SYSTEM Accesses the next system.
F6 - CHAN ASSIGN (for UHF/
VHF) or CONTROL CHANNEL
MENU (for 800/900 MHz)
A system key or FTR key is required to access this field. Brings up a screen
where you can enter the control channels for, or assign channels to,
the system.
DDCF
MOTOROLA Radio Service Software Enter or Scroll to Select System.
MCS Model:
...TRUNKING:SYSTEM:CHAN ASSIGN
System............ 1
CHANNEL ASSIGNMENT DATA
-----------------------
Rx Channel Ranges - MHz Tx Channel Ranges - MHz
------------------------------ ----------------------------------
Spacing Spacing
# Status (kHz) Start End Status (kHz) Start End
- ------ ------- ----- --- ------ ------- ----- ---
1 Enable 6.25 136.00000 136.00000 Enable 6.25 136.00000 136.00000
2 Blank Blank
3 Blank Blank
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP PREV NEXT CONTROL EXIT
SYS SYS CHANNEL
To Next Page
