207
Squelch Type Use the UP/DOWN arrow keys to select Receive, Transmit and/or
Direct (Talkaround) squelch type from among the following:
A data field for a Receive code will be displayed if PL or DPL is selected.
Code Enter the PL (Private-Line) code directly in Hz (192.8 for instance) or
use the alphanumeric code (7A for instance). Alternatively, the UP/
DOWN arrow keys may be used to scroll through standard frequencies
and codes. The code can also be selected by pressing the first letter and
then scrolling to select the correct code. Press F1 HELP while in this
field to view a list of standard frequencies and their respective codes.
Standard Private-Line Frequencies/Motorola codes are:
Note: A low-level hum or buzz in the received audio MAY be
experienced when TPL code OZ (254.1 Hz) is used. This PL code
is at the high end of the sub-audible frequency range and may
be heard in the audio under certain circumstances. Use of this
code should be avoided if possible.
CSQ Carrier Squelch (Receive Only)
PL Tone Private-Line
DPL Digital Private-Line
Disabled (Transmit and Direct Only)
Freq Code Freq Code Freq Code Freq Code Freq Code
67.0 XZ 91.5 ZZ 123.0 3Z 167.9 6Z 225.7 M4
69.3 WZ 94.8 ZA 127.3 3A 173.8 6A 229.1 9Z
71.9 XA 97.4 ZB 131.8 3B 179.9 6B 233.6 M5
74.4 WA 100.0 1Z 136.5 4Z 186.2 7Z 241.8 M6
77.0 XB 103.5 1A 141.3 4A 192.8 7A 250.3 M7
79.7 WB 107.2 1B 146.2 4B 203.5 M1 254.1 OZ
82.5 YZ 110.9 2Z 151.4 5Z 206.5 8Z
85.4 YA 114.8 2A 156.7 5A 210.7 M2
88.5 Y 118.8 2B 162.2 5B 218.1 M3
