Motorola ST7000 Basic Service Manual

Chapter 1
Model Information
This manual applies to the following ST7000, Class 3L, TETRA Handportable Terminal model:
Table 5: ST7000 Sales Models
Sales Model No. Short Description
MDH67PCL6TZ5AN ST7000 380–430 MHz PTM412DE
MDH67PCL6TZ5ANB ST7000 380–430 MHz BULK PTM412DE
1.1
ST7000 Model Specifications
NOTICE: Specifications subject to change without notice.
The following are the model specifications for sales model as listed:
Sales Model No.:
MDH67PCL6TZ5AN
MDH67PCL6TZ5ANB
Table 6: General Specifications for 380–430 MHz Sales Models
GENERAL
ETSI: ETS 300 019-1-7
Type Number:
380.0–430.0 MHz PTM412DE
Temperature Range for Transceiver:
Operating -20 °C to +55 °C
Storage -30 °C to +85 °C
Battery Types:
Standard Removable 2300 mAH IMPRES Li-Ion
Battery Voltage:
Minimum 3.2 Vdc
Nominal 3.8 Vdc
Portable Dimensions:
(HxWxD in mm)
107x60x19 mm with standard battery
132x60x19 mm with antenna
Weight:
With standard battery and stubby antenna 173 g
MN002952A01-AH
Chapter 1: Model Information
24

Motorola ST7000 Specifications

General

Weight	170g
Dimensions	132 x 49.5 x 23.4 mm
Ingress Protection	IP54
Operating Temperature	-30°C to +60°C
RF Power Output	1W
Battery Life	Up to 14 hours (standard battery)
TETRA Air Interface	ETSI EN 300 392
Security	Air Interface Encryption (AIE)
Power Output	1W
Frequency Bands	380-400 MHz, 410-430 MHz, 450-470 MHz, 806-870 MHz
Frequency Range	380-400 MHz, 410-430 MHz, 450-470 MHz, 806-870 MHz
