NOTICE: The displayed values are factory defaults and should not be changed.
BROADCAST: Not Supported
BROADCAST INTERVAL: 5 s
NEIGHBOUR CELL CHANNEL: 3500
NEIGHBOUR CELL LOCATION AREA: 0017
NEIGHBOUR CELL IDENTIFIER: 01
SLOW RE-SELECT THRESHOLD ABOVE FAST: 10 dB
FAST RE-SELECT THRESHOLD: 10 dB
SLOW RE-SELECT HYSTERESIS: 10 dB
FAST RE-SELECT HYSTERESIS: 10 dB
16 Press CONFIG. Select Call Timers & Trunking.
17 Select Transmission for Trunking Type.
18 Select Continuous for Test Set Transmit Mode.
4.5
Configuring IFR 3901/IFR 3902/IFR 3920 Setup for Japan radios
Use these procedures to configure the IFR 3901/IFR 3902/IFR 3920 setup for Japan radios only.
Prerequisites: This setup depends on the firmware version of the IFR 3901/3902/3920, the firmware
version of the radio, and the programmed parameters of the radio.
Procedure:
1 Turn ON the IFR.
2 Press Config → Config. Select System → TETRA → MS.
3 Press Config → Config. Select Configure → Channel Plan.
4 Press Select → No Plan → New Plan.
5 Enter the following parameters:
Channel Plan: JAPANUHF
Frequency Band: 4 (400.000 MHz)
Offset: 0 (+0kHz Offset)
Duplex Spacing: 5 (Reserved)
Reverse Operation: 0 (Normal)
Channel Block 1:
Lowest Channel: 2400
Highest Channel: 2580
Lowest Channel Downlink Freq: 460.000 MHz
Duplex Offset: 44.5 MHz
Channel Spacing: 25 kHz
6 Press the Save button at the top left panel on the screen.
7 To use this channel plan, press Config. Select Channel Plan → JAPANUHF.
8 Press Config → Config → Configure. Select System ID & Access Parameters.
9 Enter the following parameters:
Mobile Country Code (MCC): 440
Mobile Network Code (MNC): 5101
Base Station Color Code (BCC): 1
Location Area Code (LA): 1
10 Press Config → Config → Configure. Select Mobile Parameters.
11 Enter the following parameters:
MN002952A01-AH
Chapter 4: Test Setup and Testing
45
