Motorola ST7000 Basic Service Manual

TRANSMITTER
Class 4 (1 W) 55 dBc
Class 3L (1.8 W) 60 dBc
1.2
Sales Model Nomenclature
Table 9: Model Numbering Scheme
Typical Model
Number
AZ H 6 7 P C L 6 T Z 5 A N
Position 0 1 2 3 4 5 6 7 8 9 10 11 12
Table 10: Sales Models – Description of Positions
Position Description Value
0 Applicable Region AZ = Asia/Latin America Central Region (APAC/LACR)
AN = Australia & New Zealand (ANZ)
MD = Europe, Middle East, and Africa (EMEA)
1 Type of Unit H = Hand-Held Portable
M = Mobile Product
2 Model Series 67 = Motorola Solutions ST7000 Family
3
4 Frequency Band P = 380–430 MHz
R = 415 MHz and 465 MHz
U = 806–870 MHz
NOTICE: Values given represent range only; they
are not absolute.
5 Power Level A = 0–0.7 W
B = 0.7–0.9 W
C = 1.0–3.9 W
D = 4.0–5.0 W
E = 5.1–6.0 W
F = 6.1–10.0 W
6 Physical Packages L = Limited Controls – Limited Display
7 Channel Spacing 1 = 5 kHz
2 = 6.25 kHz
3 = 10 kHz
4 = 12.5 kHz
5 = 15 kHz
MN002952A01-AH
Chapter 1: Model Information
26

Motorola ST7000 Specifications

General

Weight	170g
Dimensions	132 x 49.5 x 23.4 mm
Ingress Protection	IP54
Operating Temperature	-30°C to +60°C
RF Power Output	1W
Battery Life	Up to 14 hours (standard battery)
TETRA Air Interface	ETSI EN 300 392
Security	Air Interface Encryption (AIE)
Power Output	1W
Frequency Bands	380-400 MHz, 410-430 MHz, 450-470 MHz, 806-870 MHz
Frequency Range	380-400 MHz, 410-430 MHz, 450-470 MHz, 806-870 MHz
