4.3.3
Duplex Test
Digital Duplex Test (Tx)
Measurement Capabilities:
• Bar charts (Tx Power, Frequency Error, Vector Error RMS)
• Spectrum Analyzer
• Power Analyzer
• Vector Analyzer
• Vector Diagrams
4.4
Configuring IFR 3901/IFR 3902/IFR 3920 Setup
Use these procedures to configure the IFR 3901/IFR 3902/IFR 3920 setup.
Procedure:
1 Turn ON the IFR.
2 Press CONFIG → CONFIG. Select System → TETRA → MS.
3 Press CONFIG → CONFIG. Select Configure → Channel Plan.
4 Press SELECT → TETRA 380+0MS.
5 Press CONFIG. Select System ID & Access Params.
6 Enter 234 for Mobile Country Code (MCC). Press Enter.
7 Enter 2392 for Mobile Network Code (MNC). Press Enter.
8 Enter 1 for Base Station Color Code (BCC). Press Enter.
9 Enter 22 for Location Area Code (LA). Press Enter.
10 Enter -110 for Min Rx Level For Access. Press Enter.
11 Enter 30 for Max Tx Level. Press Enter.
12 Enter -53 for Access Parameter. Press Enter.
13 Press CONFIG. Select Base Services.
NOTICE: You are entering base services setup. The displayed value are factory defaults
and should not be changed.
Power On Registration: Required
Power Off De-registration: Required
Priority Cell: Yes
Minimum Mode Service: May Be Used
Migration: Supported
System Wide Services: Normal Mode
TETRA Voice Service: Supported
Circuit Mode Data Service: Supported
(Reserved): Available
TETRA Packet Data Service: Available
Air Interface Encryption: Not Available
Advanced Link: Not Supported
14 Press CONFIG. Select Neighbor Cell Info.
15 Verify that the following NEIGHBOUR CELL INFO values are displayed:
MN002952A01-AH
Chapter 4: Test Setup and Testing
44
