Motorola ST7000 Basic Service Manual

Call-out Description
1 Fastening bridges
2 Press the battery cover down along the sides from the bottom to the top of the radio, to ensure
that all retention features are engaged to the main housing.
Figure 47: Attaching the Battery Cover
5.7.3.9
Installing the Antenna
Procedure:
1 Insert the screw-in base of the antenna into the antenna terminal at the top of the radio.
2 Turn clockwise until tight.
Figure 48: Installing the Antenna
MN002952A01-AH
Chapter 5: Maintenance
86

Motorola ST7000 Specifications

General

Weight	170g
Dimensions	132 x 49.5 x 23.4 mm
Ingress Protection	IP54
Operating Temperature	-30°C to +60°C
RF Power Output	1W
Battery Life	Up to 14 hours (standard battery)
TETRA Air Interface	ETSI EN 300 392
Security	Air Interface Encryption (AIE)
Power Output	1W
Frequency Bands	380-400 MHz, 410-430 MHz, 450-470 MHz, 806-870 MHz
Frequency Range	380-400 MHz, 410-430 MHz, 450-470 MHz, 806-870 MHz
