AirWorks AWK-1137C Web Console Configuration
3-42
UDP Mode
UDP is sim
ilar to TCP but is faster and more
efficient. Data can be broadcast to or received
from multiple network hosts. However, UDP
does not support verification of data and would
not be suitable for applications where data
integrity is critical. It is ideal for
message
display applications.
When Mode is set to UDP on a serial port’s Operation Modes page, you will be able to configure additional
settings such as Destination address 1 through 4, Local listen port, and Packet length.
Destination Address 1 to 4
Setting Description Factory Default
IP address range and
port (e.g.,
“192.168.1.1” to
“192.168.1.64” and
“4001”)
In UDP mode, you may specify up to 4 ranges of IP addresses
for the serial port to connect to. At least one destination range
must be provided.
The maximum selectable IP address range is 64 addresses.
However, you can enter multicast addresses in the Begin field,
in the form xxx.xxx.xxx.255. For example, enter
“192.127.168.255” to allow the AWK-1137C
to broadcast UDP
packets.
Begin: Empty
End: Empty
Port: 4001
Local Listen Port
Setting Description Factory Default
0 to 9999 This field specifies the UDP port that the AWK-1137C
listens to
and that other devices must use to contact the attached serial
device.
4001
