AirWorks AWK-1137C Web Console Configuration
3-73
Setting Description
Diagnostic script Use the Browse button to select the Moxa diagnosis script file.
Export diagnostic results Select if you want to export:
• to a file
• to a TFTP server
TFTP server IP If you have selected the TFTP option, specify the IP address of the TFTP
server.
Diagnostic script name Displays the name of the script file
Last start time Displays the start time of the last script execution
Last end time Displays the end time of the last script execution
Diagnostic status
Displays the progress of the system diagnostics
Diagnostic result Displays the result of the system diagnostics.
If you have selected the export to a file option, the system log is encrypted
and packed into a file. The limit on the log file size is 1 MB. W
hen the size of
the log file reaches 1MB another file is created. A maximum of 5 files (5MB)
will be kept for downloading. When the number of files exceeds five, the
oldest file is deleted.
Save Configuration
The following figure shows how the AWK-1137C stores the setting changes into volatile and non-volatile
memory. All data stored in volatile memory will disappear when the AWK-1137C is shutdown or rebooted
unless they are y. Because the AWK-1137C starts up and initializes with the settings stored in flash memory,
all new changes must be saved to flash memory before restarting the AWK-1137C.
This also means the new changes will not work unless you run either the Save Configuration function or the
Restart function.
