AirWorks AWK-1137C Web Console Configuration
Setting Description Factory Default
5 GHz
A Only supports the IEEE 802.11a standard
A/N Mixed Supports IEEE 802.11a/n standards, but 802.11n
at a slower speed if 802.11a clients are on the network
N Only (5 GHz) Only supports the 5 GHz IEEE 802.11n standard
Channel width (for any 11N RF type only)
Setting Description Factory Default
20 MHz Select your channel width, If you are not sure which option to
use, select 20/ 40 MHz (Auto)
20 MHz
20/40 MHz
Channel bonding
Channel bonding shows the channel used by the AP if Channel width is set to 20/40 MHz.
SSID
Setting Description Factory Default
Max. of 31 characters
The SSID of a client and the SSID of the AP must be identical for
the client and AP to be able to communicate with each other.
NOTE: An SSID cannot contain the following characters:
` ' " | ; &
MOXA
WLAN Security Settings
The AWK-1137C provides four standardized wireless security modes: Open, WEP (Wired Equivalent Privacy),
WPA (Wi-Fi Protected Access), and WPA2. Several security modes are available in the AWK-1137C by
selecting Security mode and WPA type:
• Open: No authentication, no data encryption.
• WEP: Static WEP (Wired Equivalent Privacy) keys must be configured manually.
• WPA/WPA2-Personal: Also known as WPA/WPA2-PSK. You will need to specify the Pre-Shared Key in the
Passphrase field, which will be used by the TKIP or AES engine as a master key to generate keys that
actually encrypt outgoing packets and decrypt incoming packets.
• WPA/WPA2-Enterprise: Also called WPA/WPA2-EAP (Extensible Authentication Protocol). In addition to
device-based authentication, WPA/WPA2-Enterprise enables user-based authentication via IEEE 802.1X.
The AWK-1137C can support three EAP methods: EAP-TLS, EAP-TTLS, and EAP-PEAP.
Security mode
Setting Description Factory Default
Open No authentication Open
WEP Static WEP is used
WPA WPA is used
WPA2 Fully supports IEEE 802.11i with “TKIP/AES + 802.1X”
