AirWorks AWK-1137C Web Console Configuration
3-44
Setting Description Factory Default
than one character interval within the specified baudrate. For
example, assume that the serial port is set to
1200 bps, 8 data
bits, 1 stop bit, and no parity. In this case, the total number of
bits needed to send a character is 10 bits, and the time required
to transfer one character is 8.3 ms, so the force transmit time
to be larger than 8.3 ms.
Communication Parameters
The Communication Parameters page for the serial port is where serial communication settings are
specified, such as Baud rate, Data bits, and Stop bits.
The Communication Parameters page for the serial port is where serial communication settings are
specified, such as Baud rate, Data bits, and Stop bits.
Port Alias
Setting Description Factory Default
free text (e.g.,
“Secondary console
connection”)
This is an optional free text field to help you differentiate one
serial port from another. It does not affect operation of the
AWK-1137C.
ATTENTION
Serial communication settings should match the attached serial device. Check the communication settings in
the user’s manual for your serial device.
Baud Rate
Setting Description Factory Default
75, 110, 134, 150, 300,
600, 1200, 1800, 2400,
4800, 7200, 9600,
19200, 38400, 57600,
115200, 230400,
460800, 921600
This field specifies the baudrate for the serial port.
75 to 921600: The serial port will operate at the specified
baudrate.
115200
