NPort IA5150A/IA5250A Series Getting Started
2-3
Connecting the Hardware
This section describes how to connect the NPort IA5150A/IA5250A to serial devices for first time testing
purposes. We cover Wiring Requirements, Connecting the Power, Grounding the NPort
IA5150A/IA5250A Series, Connecting to the Network, Connecting to a Serial Device, and LED
Indicators.
Wiring Requirements
ATTENTION
Safety First!
Be sure to disconnect the power cord before installing and/or wiring your NPort IA5150A/IA5250A
Series.
Wiring
Caution!
Calculate the maximum possible current in each power wire and common wire. Observe all electrical codes
dictating the maximum current allowable for each wire size.
If the current goes above the maximum ratings, the wiring could overheat, causing serious damage to your
equipment.
Temperature Caution!
Please take care when handling the NPort IA5150A/IA5250A. When plugged in, the NPort IA5150A/IA5250A’s
internal components generate heat, and consequently the casing may feel hot to the touch. When
inst
alled
with other components, make sure that there is at least 2 cm clearance on all sides of
the NPort
IA5150A/IA5250A in order to allow proper heat dissipation.
You should heed the following:
• Use separate paths to route wiring for power and devices. If power wiring and device wiring paths must
cross, make sure the wires are perpendicular at the intersection point.
NOTE: Do not run signal or communication wiring and power wiring in the same wire conduit. To
avoid interference, wires with different signal characteristics should be routed separately.
• You can use the type of signal transmitted through a wire to determine which wires should be kept separate.
The rule of thumb is that wiring that shares similar electrical characteristics can be bundled together.
• Keep input wiring and output wiring separate.
• Where necessary, it is strongly advised that you label wiring to all devices in the system.
Connecting the Power
Connect the 12-48 VDC power line with the NPort IA5150A/IA5250A’s terminal block. If the power is properly
supplied, the “Ready” LED will show a solid red color until the system is ready, at which time the “Ready” LED
will change to a green color.
Grounding the NPort IA5150A/IA5250A Series
Grounding and wire routing helps limit the effects of noise caused by electromagnetic interference (EMI). Run
the ground connection from the ground screw to the grounding surface prior to connecting devices.
WARNING
This product is intended to be mounte
d to a well-grounded mounting surface such as a metal panel.

Moxa Technologies NPort IA5150AI-T Specifications

General

Isolation	2 kV
Certification	CE, FCC
Serial interface type	RS-232/422/485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	2
Supported network protocols	ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, Rtelnet, DNS, HTTP, SMTP, SNTP, IGMP
Connectivity LEDs	Yes
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Input voltage	12 - 48 V
Safety	UL-508

Weight and Dimensions

Weight	475 g
Dimensions (WxDxH)	36 x 105 x 140 mm
