NPort IA5150A/IA5250A Series Configuring NPort Administrator
6-7
2. Unlock the NPort IA5150A/IA5250A you wish to configure if it is password protected. Right click the NPort
IA5150A/IA5250A and select Configure to start the configuration.
3. The progress bar shows that Administrator is retrieving configuration information from the specific NPort
IA5150A/IA5250A.
4. Refer to Chapter 5 for each parameter’s function definition. To modify the configuration, you must first click
in the modify box to activate the parameter setting box.
ATTENTION
You can simultaneously modify the configurations of multiple NPort IA5150A/IA5250As that are of the same
model.
To select multiple NPort IA5150A/IA5250As, hold down the Ctrl key when selecting
additional NPort
IA5150A/IA5250As, or hold down the Shift key to select a group of NPort IA5150A/IA5250As
.
Upgrading the Firmware
Follow these steps to upgrade the firmware of an NPort IA5150A/IA5250A.
1. To start NPort Administrator, click Start  NPort Administration Suite  NPort Administrator.

Moxa Technologies NPort IA5150AI-T Specifications

General

Isolation	2 kV
Certification	CE, FCC
Serial interface type	RS-232/422/485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	2
Supported network protocols	ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, Rtelnet, DNS, HTTP, SMTP, SNTP, IGMP
Connectivity LEDs	Yes
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Input voltage	12 - 48 V
Safety	UL-508

Weight and Dimensions

Weight	475 g
Dimensions (WxDxH)	36 x 105 x 140 mm
