NPort IA5150A/IA5250A Series Web Console Configuration
Destination IP address parameter can use both IP address and Domain Name
. For some applications,
the
user may need to send the data actively to the remote destination domain name.
Designated Local Port 1/2/3/4
Setting Factory Default Necessity
TCP Port No. 5011 (Port 1)
5012 (Port 2)
5013 (Port 3)
5014 (Port 4)
Required
Connection control
Setting Factory Default Necessity
Startup/None, Any
Character/None,
Any Character/Inactivity Time,
DSR ON/DSR OFF, DSR ON/None,
DCD ON/DCD OFF, DCD ON/None
Startup/None Required
The meaning of each of the above settings is given in the table below. In general, both the Connect condition
and Disconnect condition are given.
Connect/Disconnect Description
Startup/None
(default)
A TCP connection will be established on startup, and will remain active indefinitely.
Any Character/None A TCP connection will be established when any character is received from the serial
interface, and will remain active indefinitely.
Any Character/
Inactivity Time
A TCP connection will be established when any character is received from the serial
interface, and will be disconnected when the Inactivity time out is reached.
DSR On/DSR Off A TCP connection will be established when a DSR “On” signal is
be disconnected when a DSR “Off” signal is received.
DSR On/None A TCP connection will be established when a DSR “On” signal is received, and will
remain active indefinitely.
DCD On/DCD Off A TCP connection will be established when a DCD “On” signal is
be disconnected when a DCD “Off” signal is received.
DCD On/None A TCP connection will be established when a DCD “On” signal is
remain active indefinitely.
