USER MANUAL
compact
MRU GmbH, D-74172 Neckarsulm
2.4. Connectors at the side
Condensate separator Gas cooler
2.5. Condensate separator
Disconnect the hoses at the gas entrance port (1) and the gas exit port (2).
Lift the condensate separator upwards out of the mounting bracket next to the base unit.
Liquid that is poured out of the condensate separator can be lightly acidic.
The condensate show glass and the bottom plug are screwed into each other and can easily be
taken apart from each other (for cleaning and drying the condensate separator). He filter
housing can also be unscrewed to replace the pleated filter. Please pay special attention when
reassembling the condensate separator that all the O-Rings are in the right position and that
they are not damaged. After each dismounting of the condensate separator we recommend you
to perform an instruments leak proof test.
There is a pleated filter mounted in the condensate separator. This filter filters rough particles
out of the flue gas. This pleated filter is washable and can be reused up to five times (filter must
be completely dry before being used again). The filter should be replaced or washed when it
changes its color from to brown or grey. A frequently washed or replaced filter will avoid dirt
getting inside the analyzer will therefore avoid damage to your analyzer.
Connector sample gas probe
