mru NOVA compact - Operating the Analyzer; The Display

USER MANUAL
NOVA
compact
MRU GmbH, D-74172 Neckarsulm
14 / 50
3. Operating the analyzer
3.1. The Display
All information required to operate the analyzer is displayed as shown below.
Keypad
ON/OFF
Press to start the analyzer without delay. The power off function will
be delayed to protect the sensors. If there is not enough ambient air
the analyzer will recommend the purging of the sensors.
Function Keys
Activates the functions seen on the display (2 function key bar)
Menu key
Will show all available functions in the window that is currently in use
– also those which have an individual key on the key pad like the
printer and the three function keys.
NOTE:
By pressing this button, you get an overview of all functions.
ESC
Abort or return to the menu above
Arrow Keys
Jump in between lines, change values
OK
Confirmation key, select a marked menu point
Printer
Activates the printer function in the measurement and service
window.
1
Menu bar
2
Function key bar
3
Display panel
- Menu
- Measurement value,…
4
Zeroing active
5
SD-Card in the slot
- Indication green Read- and write access
- Indication yellow only Read access (SD-Card write protected)
6
Battery charge condition
