USER MANUAL NOVAcompact
MRU GmbH, D-74172 Neckarsulm
39 / 50
11. Appendix
11.1. Text input
A numbers of texts and names can be changed to your own needs.
(for example: the names of the user defined fuel types, site names, the names of the
measurement programs)
When you select the text input, the following window will pop up:
11.2. Asking the user for a decision (pop up window)
The analyzer will ask you now and then to confirm the action that will be taken.
11.3. Firmwareupdate
Switch ON the device.
Select F3 settings/Device info
For the case that there should be problems by the update we need some information of you.
Please write down your Firmware-Version (e.g. 1.33.00)__________________
Please write down your serial number (e.g. 301231)___________________
You need the latest file `1102.fwb'. In case you get it in a zip archive you have to extract
it before usage. This file contains all firmware types and the analyser will extract the
correct type out of this file automatically.
Performing an update:
• copy the file '1102.fwb' to a SD card in the root directory (that means in no directory)
• insert the SD card into the analyser and switch on the analyzer
• wait until you will be asked: Firmware found. Install now?
• acknowledge with 'install'
• the update mechanism starts……….
• wait about 45 seconds, press any key at this time
• then the analyser will reboot with the new firmware
• confirm with „OK“
• finished
, , ,
Select a letter, number or sign
F1 – delete
The letter left of the cursor will be deleted
F2 – insert
Selected letter or number will be inserted
F3 – over write
Selected letter or number will over write the current letter or
number
ESC
Abort the window, changes will NOT be saved
,
Select a line
OK
Confirm the action
ESC
Abort the window, changes will NOT be saved
