ALTAIR 5X/ALTAIR 5X IR
GB
13
The ALTAIR 5X and ALTAIR 5X IR detectors are available with either a mono-
chrome or colour display.
While the device can detect up to 30 % oxygen in ambient air, it is approved for use
only up to 21 % oxygen.
The alarm levels for the individual gases are factory-set and can be changed
through the device Setup Menu. These changes can also be made through
MSA Link Software. Ensure that the latest version of the MSA Link software has
been downloaded from MSA’s website www.msanet.com.
It is recommended that after making changes using MSA Link software, the device
should be turned off and on.
2.2 Device Hardware Interfaces
Device operation is dialog driven from the display with the aid of the three function
buttons [→ Fig. 1].
The devices have three buttons for user operation. Each button can function as a
"soft key", as defined directly above the button.
Button Definitions
When the button and the button are pressed simultaneously while in normal
measure mode, the Setup mode can be entered after the password is confirmed.
Button Description
ON/OFF The ON/OFF button is used to turn device ON or OFF and to con-
firm user action selections.
The button is used to page down through data screens or to de-
crease the values in Set-up mode through data screens or to de-
crease the values in Setup mode. This button is also used to initiate
a Bump Test for the installed sensors, directly from the MEASUR-
ING page.
If the user is granted access to the MotionAlert setting feature, this
button can be used to activate the InstantAlertTM alarm.
The button is used to reset peak, STEL TWA and alarms [where
possible] or perform calibration in measuring mode. It is also used
as page up or to increase the values in set-up mode.
