ALTAIR 5X/ALTAIR 5X IR
GB
27
Motion Alert Activation Page
When the MotionAlert feature is active, the + symbol appears. The device enters
pre-alarm when no motion is detected for 20 seconds. This condition can be cleared
by moving the device. MotionAlert is turned OFF each time the device is powered
OFF. After 30 seconds of no motion, the full MotionAlert alarm is triggered. This
alarm can only be cleared by pressing the button. This page displays if it was se-
lected in Setup Mode. To activate or deactivate the MotionAlert feature, press the
button while the MOTIONALERT ACTIVATION page is displayed.
2.5 Sensor Missing Alarm
Enabled IR and XCell sensors are continuously monitored for proper function. If,
during operation, the IR or an XCell sensor is detected as failed or disconnected,
this alarm message appears.
-"SENSOR MISSING" flashes on the display.
- The problematic sensor is indicated.
- The alarm sounds and the Fault and Alarm LEDs flash.
- The alarm can be silenced by pressing the button; no other pages can be
viewed.
- If there is a sensor error the device will not be operable.
2.6 Monitoring Toxic Gases
The device can monitor the concentration of a variety of toxic gases in ambient air.
Which toxic gases are monitored depends on the installed sensors.
The device displays the gas concentration in parts per million [ppm] or mg/m
3
on
the Measuring page.
The device has four gas alarms:
-HIGH Alarm
- LOW Alarm
-STEL Alarm
-TWA Alarm
Attention!
If an alarm is triggered while using the device, leave the area
immediately.
Remaining in the area under such circumstances can cause serious
personal injury or death.
