MSA Ultima X User Manual

GB
DECLARATION OF CONFORMITY MSA
3-2 ULTIMA
®
X
3 TM
Marking, Certificates and Approvals according to the
Directive 94/9/EC (ATEX).
Manufacturer:
Mine Safety Appliances Company
1000 Cranberry Woods Drive
Cranberry Township, PA 16066 USA
Product: ULTIMA
®
XE / X
3 TM
Type of protection: EN 50 014, EN 50 018
Performance: none
ULTIMA XE/ X
3
MAIN:
UB = 19V - 30V, Int.Relais + LEDs,
Digital I/O = 0-5V ,3- wire, (GND, Signal+ , Signal -)
Marking:
ULTIMA
®
XE / X
3 TM
II 2G EEx d IIC T5
-40°C ≤ Ta ≤ +60°C
Sensors:
ULTIMA XE, ULTIMA XIR: unchanged
Maximum 1x ULTIMA XIR and 2x ULTIMA XE
EC-Type Examination Certificate: DMT 02 ATEX E 202 X
Quality Assurance Notification: 0080
Year of Manufacture: see Label
Serial Nr.: see Label
EMC Conformance according to the Directive 89/336/EC
EN 50 270 Typ 2* EN 61 000 - 6 - 3
* EN 61000-4-6: occasional transmission error can appear.
A fault check has to be used at the receiver unit.

MSA Ultima X Specifications

General

Ingress Protection	IP66/67
Enclosure	Explosion-proof
Detection Method	Electrochemical, Infrared, Catalytic Bead
Gases Detected	Combustible gases, Toxic gases, Oxygen
Display	LCD
Output	4-20 mA, HART
Housing Material	Stainless steel
Certifications	ATEX, IECEx, UL, CSA, SIL 2
